TB 505/805/1105

TB-505/805/1105 is a narrow site line curtainwall framing

Thermally broken tubular and split aluminum sections
Fully pressure-equalized rain screen design
Narrow sight-line 1-3/4″ profiles in 4″, 6″ and 8″ back sections
SSG-2 and Capped systems available
Shop fabricated, available pre-glazed, partially glazed, or unglazed
Range of “beauty cap” configurations
TB V237 Vent insert options available (Casement, Awning & Hopper)
Insulated metal panel spandrel infill
Continuous Air-Vapour Retarder throughout, primarily in-line with glazing surfaces
Steel reinforcing available
6063 Alloy T6 aluminum extruded alloy
1 – 5 year warranty as specified

Engineered to more stringent L/175 deflection threshold
Superior resistance to air and water infiltration
Individual glass units (or infill panels) may be reglazed without requiring removal of structural components
Diverse framing options available
Options of shop glazing and field glazing allows flexibility of installation and opportunity to accelerate install schedule

Current certified test reports ensuring full ASTM compliance.
